Machine Vision Industrial Cameras

The New Benchmark in Industrial Imaging Technology

Complete Product Line Guide — Empowering Smart Manufacturing with Precision Vision

1. About Us — Your One-Stop Machine Vision Camera Partner

We are a leading manufacturer and supplier of machine vision industrial cameras, dedicated to delivering high-performance imaging solutions across the full spectrum of industrial inspection, scientific research, and automation applications. Our comprehensive product portfolio spans 11 major product lines — from entry-level GigE cameras to cutting-edge 410-megapixel CoaXPress cameras and dual-fiber high-speed line scan systems.

Our cameras are deployed globally in semiconductor fabs, PCB inspection lines, flat panel display (FPD) production, medical imaging, automotive assembly, photovoltaic manufacturing, logistics sorting, and scientific research institutions. We serve thousands of system integrators, OEM manufacturers, and end users worldwide.

2. Six Core Technical Advantages

In the highly competitive smart manufacturing landscape, camera performance, reliability, and cost-efficiency directly determine the competitiveness of your machine vision system. Here are the six core advantages that make our cameras the preferred choice for leading system integrators worldwide.

2.1 Global Shutter Technology — Zero Motion Blur

The majority of our camera lineup features global shutter sensors that expose all pixels simultaneously, completely eliminating the "rolling shutter" distortion artifacts seen in fast-moving object inspection. This is critical for high-speed production lines, robotic pick-and-place, and motion analysis applications. Global shutter models are available from 0.3MP to 65MP across GigE, USB3.0, CoaXPress, and fiber product lines.

2.2 Built-in Hardware ISP — Reduce Host CPU Load

Our cameras feature an embedded hardware image signal processor (ISP) that handles Gamma correction, lens distortion correction, flat-field correction, 3D noise reduction, and other image enhancement tasks directly in the camera. This offloads significant processing burden from the host PC, enabling higher throughput in multi-camera systems and freeing up CPU resources for algorithm execution.

2.3 Multi-Interface Support — Covering All Industrial Standards

2.4 Resolution Range: 0.3MP to 410 Megapixels

Our lineup covers an unprecedented resolution range — from 0.3 megapixels (300K) for high-speed, small-FOV applications up to 410 megapixels (24592 × 16704, MV-PX41000C/M — China's first 410MP industrial camera). Line scan cameras reach up to 16K pixels with 256-level TDI, meeting the most demanding precision measurement and large-field inspection requirements.

2.5 Premium Sensor Partners — SONY, ON Semiconductor, Gpixel & More

We partner with the world's leading image sensor manufacturers — SONY IMX series, ON Semiconductor AR/PYTHON series, OmniVision, Gpixel GMAX series, and SmartSens — ensuring consistent product performance, technology leadership, and stable supply chain for your production needs.

2.6 Plug-and-Play Open Ecosystem — Accelerate System Integration

All cameras comply with GigEVision, USB3 Vision, and GenICam international standards. Direct compatibility with Halcon, VisionPro, LabVIEW, OpenCV, and MATLAB means no custom driver development needed. Full C/C++, C#, and Python SDKs are provided, significantly shortening your development cycle from concept to production deployment.

3. Complete Product Line Overview — 11 Product Series

We offer industrial cameras covering all interfaces, resolutions, and application scenarios, making us one of the very few manufacturers capable of providing a true "one-stop" industrial camera sourcing solution.

■ Line 1: Ethernet Industrial Cameras

1-A  GigE Area Scan Cameras — GE / GEF / GED / GEC Series

Resolution: 0.3MP to 20MP, CCD or CMOS options

Interface: Gigabit Ethernet, up to 100m, optional POE power supply

Unique packet retransmission technology ensures zero data loss

Up to 7 channels of optically isolated GPIO, external trigger & strobe sync

Seamless compatibility with Halcon, VisionPro, LabVIEW — plug and play

Key Models: MV-GE130GM (1.2MP Global Shutter, 60.75fps) | MV-GE231GC/M (2MP, IMX249) | MV-GE500C/M (5MP)

1-B  GigE Line Scan Cameras — GEL / GELM Series

Line rate up to 27.5kHz, RGB three-line true color output

Encoder synchronous triggering, 2-line SUM hardware binning

1-C  2.5GigE Industrial Cameras

2.5× bandwidth of GigE, backward compatible with GigE infrastructure

1-D  10GigE Area Scan Cameras — XGC Series

Resolution: 0.5MP to 65MP, max frame rate 1609.25 FPS

1200 MB/s effective bandwidth — 10× that of GigE

Shares GigEVision/GenICam SDK with GigE cameras for easy migration

1-E  10GigE Line Scan Cameras — XGL Series (incl. 256 TDI)

General series: max line rate 150kHz (8-bit), 87.7kHz (12-bit)

256-TDI series: 5μm pixel, 4096/8192/16384 pixels, up to 250kHz

Dramatically reduces light source requirements — ideal for dark-field inspection

■ Line 2: USB Industrial Cameras

2-A  USB3.0 Area Scan Cameras — SUA / SUF / SUC Series

Resolution: 0.3MP to 25MP, global & rolling shutter options

Frame rate: up to 791fps (0.3MP model)

8-bit to 12-bit RAW output, compatible with Windows / Linux / ARM Linux

Fully compatible with GigE camera SDK for seamless system migration

2-B  USB2.0 Industrial Cameras — UBS / UB Series

0.3MP to 10MP, CCD/CMOS options, supports 32+ simultaneous cameras

No external power supply needed — USB bus powered, plug and play

■ Line 3: CoaXPress High-Speed Industrial Cameras

3-A  CoaXPress Area Scan Cameras — PX Series (CXP-12)

CXP-12 interface: max 4850 MB/s (4× faster than 10GigE, 12× USB3.0)

2.5MP to 150MP, max 1876.5 fps (2.5MP model)

Flexible 1/2/4 channel combinations, CoaXPress 2.1 trigger + power over coax

Designed for semiconductor wafer inspection, large-area FPD, ultra-high-speed motion analysis

3-B  CoaXPress Line Scan Cameras — PXL Series

16K resolution, RGB true color, 2-TDI mode, max line rate 125kHz

4850 MB/s bandwidth, HD-BNC industrial cable connection

■ Line 4: Fiber Optic Industrial Cameras (Flagship New Products)

4-A  Dual 16G Fiber Area Scan Cameras — H2FL Series

Dual SFP28 fiber interfaces: 32Gbps total bandwidth — 3× that of 10GigE

Resolution from 2.5MP to 250MP — diverse high-precision imaging applications

Superior EMI resistance: stable transmission up to 75 meters

CXP-level performance at 10GigE-level cost — outstanding value

Advanced features: 3D noise reduction, ISP acceleration, GenICam compliant

Paired with MV-CHF20 frame grabber: PCIe 4.0×4, 2GB frame buffer, passive cooling

Key Models: MV-H2F2500GM (2.5MP) | MV-H2FL84M (8K+256TDI, 440kHz line rate — for FPD/PCB/Semiconductor)

■ Line 5: Board Cameras / Modules

GigE Board Camera: GEM Series — ultra-thin, single board, C/M12/bare board options

USB3.0 Board Camera: SUM Series — ideal for embedded integration

Binocular Camera Module: MSU/MGE Series — adjustable baseline, FPC flexible cable

Applications: robotics, AGV, drones, embedded vision systems

■ Line 6: Smart Industrial Cameras

6-A  X86 Smart Cameras — ITA / ITAE / ITSI Series

Intel Atom / N4120 processor, 2-4GB RAM, HDMI output, integrated light source controller

Supports Windows 10 and Ubuntu 16.04, runs Halcon and other vision algorithms on-board

M12 aviation connector, RS232, trigger I/O — ruggedized industrial design

■ Line 7: Special Industrial Cameras

Far Infrared Thermal Imager (GF Series): GigE, NETD ≤55mK, 50Hz — temperature anomaly detection

Short-wave Infrared Area Scan: InGaAs detector, 400-1700nm, 2592×2056 @ 120fps, TEC cooling

Short-wave Infrared Line Scan: 900-1700nm, up to 40kHz — fruit sorting, material inspection

UV Industrial Camera: Dedicated UV sensor for fluorescence and UV curing inspection

Coaxial Mini Camera (MV-MS136GM/C): 14×14mm body, <16g, <1W power — single card drives 12 cameras

■ Line 8: Special-Structure Cameras

Micro Industrial Camera: 20×18mm cross-section, M12 lens mount — confined space inspection

Pen Mini Camera: Pen-shaped form factor — narrow channel access

90° Right-Angle Camera: Vertical height only 29mm — solves installation space constraints

■ Line 9: 3D Industrial Cameras

3DL Laser Profiler: Scheimpflug principle, Z-axis repeatability at micrometer level, 2048 pts/profile, 10kHz scan

3DF Structured Light (MV-3DF501GM-HG): DLP module, Z-axis 4μm accuracy, 2448×2048 @ 59fps

Applications: consumer electronics, industrial inspection, healthcare, robotics

■ Line 10: Expansion Cards

■ Line 11: OEM/ODM Customization Service

We provide end-to-end customization services — from sensor selection and interface protocol to mechanical design and software SDK:

Spectral Customization: UV, visible light, NIR, SWIR (short-wave IR), LWIR (thermal)

Interface Customization: USB2.0/3.0, GigE, 10GigE, Fiber Optic, CXP, wireless

Sensor Options: SONY, ON Semiconductor, OmniVision, Gpixel, SmartSens, and more

Feature Customization: Programmable I/O, autofocus, IP67 waterproof housing, battery power, integrated lighting

Process: Requirements → Design → Prototype → Testing → Mass Production & Delivery

4. Key Application Industries

5. Why Partner With Us — Distribution & OEM Advantages

We don't just sell cameras — we provide a complete machine vision ecosystem and robust commercial partnership support. By choosing us as your camera supply partner, you gain:

6. Contact Us — Get Product Catalog & Partnership Details

We welcome inquiries from system integrators, distributors, OEM/ODM manufacturers, and end users worldwide. Our team responds within 24 hours.
